Control ApproachOfficial claim
Classical control
Fourier IntelligenceGR
GR-1
Price
Unknown
Type
Humanoid Robots
Subtype
Human-scale Humanoid
Status
Commercial
Release Date
2023
Country/Region
China
Last Verified
2026-07-29
54 DOF
Total DOF
1.65 m
Height
55 kg
Weight
3 kg per hand
Payload
Fourier GR-1 is the base commercial humanoid variant with a 54-DOF body, 44 actuators, dexterous hands, 5 km/h walking speed, 3 kg single-handed payload and 460 Wh battery capacity for general-purpose work and research.
1 / 1
Intelligence Profile
Capability Map
MobilityOfficial claim
Walking
The official GR-1 documentation lists gait motion and describes human-like gait motion control.
MobilityOfficial claim
Balance
Fourier describes a dynamic coordination self-balance algorithm and lists static standing as a motion mode.
MobilityOfficial claim
Navigation
The documentation describes visual perception for obstacle avoidance and environmental awareness.
ManipulationOfficial claim
Grasping
The official variant table lists end-effector gripping, and the document describes the hand as capable of versatile grasping.
InteractionOfficial claim
Speech interaction
The official document describes an onboard speech-recognition system and natural language interaction through a multimodal LLM.
Hardware Specification
Physical Specifications
Arm Span
1680 mm
Frame Material
Skeleton casing
Height
1.65 m
Materials
Aluminum alloy + engineering plastic
Standing Dimensions
1650 × 515 × 320 mm
Weight
55 kg
Mobility & Payload
Single-arm Payload
3 kg
Payload
3 kg per hand
Peak Joint Torque
230 N·m
Walking Speed
1.388889 m/s
Degrees of Freedom
DOF per Arm
7 per arm
DOF per Hand
11 per hand
Head DOF
3 DOF
DOF per Leg
6 per leg
Total DOF
54 DOF
Waist DOF
3 DOF
Mechanical Structure
Actuator Model
Fourier Smart Actuator (FSA)
End-Effector
Dexterous hand
Joint Count
44
Sensors
Depth Camera
RealSense
Battery and Runtime
Battery Capacity
460 Wh
Charger
46 V 2 A
Max Power
550 W
Power Supply
46.2 V
Compute Platform
Onboard Compute
Intel Core i7-13700H, 6P+8E, 20 threads, 1.6/5.0 GHz
Interaction and Communication
Remote Controller
Touchscreen remote controller
Development and Expansion
Secondary Development (SDK)
SDK support for external development
Commercial Status
Status
Commercial
Price
Unknown
Release Date
2023
