Deep RoboticsLYNX M20
山猫 M20 Pro
Contact sales
Type
Quadruped Robots
Status
Unknown
Release Date
Unknown
Warranty
Unknown
Location
Unknown
Last Verified
2026-07-29
0.57 m
Height
35 kg
Weight
15 kg
Payload
LYNX M20 is an industrial wheeled-legged robot for difficult terrain and hazardous environments. Weighing 35 kg, it combines omnidirectional obstacle avoidance, point-cloud surround view, autonomous navigation, a 15 kg payload, IP66 protection and hot-swappable batteries for inspection, rescue, tunnels and research.
1 / 1
Specifications
Body Specifications
Height
0.57 m
Ingress Protection (IP)
IP66
Length
820 mm
Operating Temperature
-20℃ to 55℃
Standing Dimensions
820 mm × 430 mm × 570 mm
Weight
35 kg
Width
430 mm
Performance
Max Gradient
45°
Max/Limit Payload
50 kg
Max Speed
5 m/s lab-tested max speed
Payload
15 kg
Max Step Height
25 cm continuous stair height; 80 cm single-step height
Walking Speed
2 m/s operating max speed
Sensors
Camera
2 × wide-angle cameras
LiDAR
2 × 96-line LiDAR, 360° × 90°, ~860000 pts/s
Obstacle Avoidance
Omnidirectional obstacle avoidance
Battery and Runtime
Charging Time
1.5 h
Range
15 km unloaded; 12 km loaded (15 kg)
Runtime
2.5-3 h (loaded/unloaded)
Compute Platform
AI Compute Module
Dual octa-core 64-bit industrial processors (16GB+128GB) × 3
Onboard Compute
Dual octa-core 64-bit industrial processors (16GB+128GB) × 3
Interaction and Communication
External Port
72V power input, Gigabit Ethernet
Lighting
Front/rear bidirectional lighting
Smart Navigation
Point cloud surround view
OTA Update
OTA upgrades
